I2C Arduino Modüllerinin Adres Numarası Nasıl Bulunur?

7 Şubat 2022

Arduino projelerimizde I2C modüllerini kullanırken cihazın adres numarasını biliyor olmamız gerekiyor. Çoğu yaygın modülün hangi I2C adresine sahip olduğu biliniyor ve internette paylaşılan örneklerden bulunabiliyor.

Ancak I2C adresi hakkında hiçbir fikrimiz olmayan bir modül ile karşılaştığımızda veya modülümüz düşündüğümüz adres ile çalışmadığında ne yapmalıyız? Bu yazıda Arduino’ya bağlı I2C destekli modüllerin adres numaralarını bulmayı öğreneceğiz.

I2C iki elektronik cihaz arasında iletişim kurulmasını sağlayan özgün bir protokol. Bir adet master (sahip) cihaz ve teoride 127 adede kadar slave (köle) cihaz kullanımına izin veriyor. Arduino’muz bu durumda master olarak çalışıyor ve kullandığımız I2C destekli modüller de slave modunda üretiliyor.

I2C destekli modüller Arduino Uno ve Nano’ya SDA (veya A4) ve SCL (veya A5) adı verilen iki pin ile bağlanır. Arduino Mega 2560 kullanıyorsak D20 (SDA) ve D21 (SCL) pinlerini kullanmalıyız.

Bu kod sadece klasik bir tarama yapmakla kalmaz; Arduino Uno R4, ESP32, STM32 veya RP2040 gibi modern kartlarda bulunan birden fazla donanımsal I2C portunu (Wire, Wire1, Wire2, vb.) otomatik olarak tespit edip tarar. Dahası, kodun içerisinde geniş bir cihaz veritabanı bulunuyor. Ekranda sadece “0x3C” görmek yerine “0x3C => OLED (SSD1306 / SH1106)” gibi net ve anlaşılır sonuçlar alırsınız.

Kodun en can alıcı özelliklerinden biri de otomatik Multiplexer (Çoklayıcı) taramasıdır. Eğer projenizde aynı adrese sahip birden fazla sensör kullanmak için TCA9548A gibi bir I2C çoklayıcı kullanıyorsanız, tarayıcı bu entegreyi otomatik olarak algılar ve arkasına bağlı olan 8 farklı kanalı tek tek tarayarak sonucu size ağaç yapısında sunar. Ayrıca I2C bağlantılarındaki kararsızlıkları önlemek adına sıkı bir hata kontrol algoritması kullanılarak “hayalet” cihazların listeye girmesi engellenmiştir.

Kullanımı son derece basit: Kodu kopyalayın, kartınıza yükleyin ve Seri Port Ekranı’nı 115200 baud hızında açın. Saniyeler içinde tüm I2C hattınızın röntgenini çekmiş olacaksınız!

Arduino’da iyi olmak için öncelikle elektronikte iyi olmak gerekir. Türkiye’nin en iyi temel elektronik eğitim seti ARDUINO ÖNCESİ TEMEL ELEKTRONİK EĞİTİM VE DENEY SETİ‘ni keşfedin. Gereksiz bilgilerden arındırılmış basit ve eğlenceli anlatımla ELEKTRONİK öğrenin ve Arduino’ya METE HOCA farkıyla güçlü başlayın!

Sketch kodunu kopyalamak için pencerenin sağ üst köşesindeki butona tıklayabilirsiniz.

/*
 * ╔══════════════════════════════════════════════════════════════════╗
 * ║           METE HOCA ADVANCED I2C SCANNER                         ║
 * ╠══════════════════════════════════════════════════════════════════╣
 * ║ OVERVIEW:                                                        ║
 * ║ This advanced I2C scanner detects devices across multiple        ║
 * ║ hardware I2C buses (Wire, Wire1, Wire2, Wire3). It identifies    ║
 * ║ the connected modules and maps them to their common names.       ║
 * ║                                                                  ║
 * ║ HOW TO USE:                                                      ║
 * ║ Upload the code to your microcontroller, open the Serial Monitor ║
 * ║ at 115200 baud, and observe the output. The scanner will refresh ║
 * ║ automatically based on the SCAN_INTERVAL_MS definition. Custom   ║
 * ║ SDA/SCL pins can be defined manually for ESP32/RP2040 boards.    ║
 * ║                                                                  ║
 * ║ SUBTLE POINTS & NUANCES:                                         ║
 * ║ • Mux Recursion: Automatically detects TCA9548A multiplexers     ║
 * ║   (0x70-0x77) and scans all 8 of their sub-channels individually.║
 * ║   (If this causes conflicts, comment out ENABLE_MUX_SCAN).       ║
 * ║ • Strict Validation: endTransmission() must return exactly 0.    ║
 * ║   This filters out NACKs, timeouts, and buffer overruns.         ║
 * ║ • Arduino Uno R4 WiFi: Be aware that the physical Qwiic          ║
 * ║   connector on this board is tied to Wire1, not the default Wire.║
 * ║ • Sorting Algorithm: Results are strictly sorted by Port ->      ║
 * ║   Mux Address -> Mux Channel -> Device Address for readability.  ║
 * ╚══════════════════════════════════════════════════════════════════╝
 */

#include <Wire.h>

#define SCAN_INTERVAL_MS  3000
#define SCAN_DELAY_US     150
#define MAX_FOUND         32

#define ENABLE_MUX_SCAN

#if defined(WIRE_INTERFACES_COUNT)
  #if WIRE_INTERFACES_COUNT >= 2
    #define HAS_WIRE1
  #endif
  #if WIRE_INTERFACES_COUNT >= 3
    #define HAS_WIRE2
  #endif
  #if WIRE_INTERFACES_COUNT >= 4
    #define HAS_WIRE3
  #endif
#else
  #if defined(ARDUINO_UNOR4_WIFI)   || defined(ARDUINO_NANO_R4)    || \
      defined(ARDUINO_ARCH_RP2040)  || defined(ARDUINO_ARCH_STM32) || \
      defined(CORE_TEENSY)          || defined(ARDUINO_SAM_DUE)    || \
      defined(ARDUINO_ARCH_ESP32)   || defined(ARDUINO_UNO_Q)
    #define HAS_WIRE1
  #endif
#endif

struct FoundDevice {
  uint8_t address;
  uint8_t portIdx;
  uint8_t muxAddress;
  uint8_t muxChannel;
};

FoundDevice foundDevices[MAX_FOUND];
uint8_t foundCount = 0;

bool probeAddress(TwoWire& wire, uint8_t address) {
  wire.beginTransmission(address);
  uint8_t error = wire.endTransmission();
  delayMicroseconds(SCAN_DELAY_US);
  return (error == 0);
}

bool isDevicePresent(const FoundDevice* deviceArray, uint8_t count,
                     uint8_t address, uint8_t portIdx,
                     uint8_t muxAddress, uint8_t muxChannel) {
  for (uint8_t i = 0; i < count; i++) {
    if (deviceArray[i].address    == address    &&
        deviceArray[i].portIdx    == portIdx    &&
        deviceArray[i].muxAddress == muxAddress &&
        deviceArray[i].muxChannel == muxChannel) return true;
  }
  return false;
}

void addDevice(uint8_t address, uint8_t portIdx,
               uint8_t muxAddress, uint8_t muxChannel) {
  if (foundCount >= MAX_FOUND) return;
  if (isDevicePresent(foundDevices, foundCount,
                      address, portIdx, muxAddress, muxChannel)) return;
  foundDevices[foundCount++] = {address, portIdx, muxAddress, muxChannel};
}

#ifdef ENABLE_MUX_SCAN
void scanMux(TwoWire& wire, uint8_t portIdx, uint8_t muxAddress) {
  for (uint8_t channel = 0; channel < 8; channel++) {

    wire.beginTransmission(muxAddress);
    wire.write(1 << channel);
    if (wire.endTransmission() != 0) continue;
    delayMicroseconds(200);

    for (uint8_t address = 1; address < 127; address++) {
      if (address >= 0x70 && address <= 0x77) continue;
      if (probeAddress(wire, address)) {
        addDevice(address, portIdx, muxAddress, channel);
      }
    }

    wire.beginTransmission(muxAddress);
    wire.write(0x00);
    wire.endTransmission();
    delayMicroseconds(100);
  }
}
#endif

void scanPort(TwoWire& wire, uint8_t portIdx) {
  for (uint8_t address = 1; address < 127; address++) {
    if (probeAddress(wire, address)) {
      addDevice(address, portIdx, 0, 0);
#ifdef ENABLE_MUX_SCAN
      if (address >= 0x70 && address <= 0x77) {
        scanMux(wire, portIdx, address);
      }
#endif
    }
  }
}

void sortResults() {
  if (foundCount < 2) return;
  for (uint8_t i = 0; i < foundCount - 1; i++) {
    for (uint8_t j = i + 1; j < foundCount; j++) {
      bool swapNeeded = false;
      const FoundDevice& a = foundDevices[i];
      const FoundDevice& b = foundDevices[j];

      if      (a.portIdx  > b.portIdx ) swapNeeded = true;
      else if (a.portIdx == b.portIdx ) {
        if      (a.muxAddress  > b.muxAddress) swapNeeded = true;
        else if (a.muxAddress == b.muxAddress) {
          if      (a.muxChannel  > b.muxChannel) swapNeeded = true;
          else if (a.muxChannel == b.muxChannel && a.address > b.address) swapNeeded = true;
        }
      }

      if (swapNeeded) {
        FoundDevice temp = foundDevices[i];
        foundDevices[i]  = foundDevices[j];
        foundDevices[j]  = temp;
      }
    }
  }
}

void printDeviceNames(uint8_t address) {
  bool isFirst = true;
  #define PRINT_NAME(s) do { if (!isFirst) Serial.print(F(", ")); \
                             Serial.print(F(s)); isFirst = false; } while(0)

  if (address == 0x0D) PRINT_NAME("QMC5883L (Compass Clone)");
  if (address == 0x0E) PRINT_NAME("Pololu Tic (Stepper Motor Driver)");
  if (address == 0x10) PRINT_NAME("VEML7700 (Light)");
  if (address == 0x14) PRINT_NAME("MAG3110 (Magnetometer)");
  if (address == 0x15) PRINT_NAME("Modulino Latch Relay");
  if (address == 0x18) { PRINT_NAME("MCP9808 (High-Precision Temp)"); PRINT_NAME("SparkFun Qwiic Relay"); }
  if (address == 0x19) { PRINT_NAME("Modulino LED Matrix"); PRINT_NAME("LSM303 (Compass/Accel)"); }
  if (address == 0x1A) PRINT_NAME("MAX9744 (Audio Amplifier)");
  if (address == 0x1C) PRINT_NAME("MMA8452Q / FXOS8700 (Accelerometer)");
  if (address == 0x1D) PRINT_NAME("Modulino Vibro");
  if (address == 0x1E) { PRINT_NAME("Modulino Buzzer"); PRINT_NAME("HMC5883L / LIS3MDL (Compass)"); }

  if (address == 0x20) { PRINT_NAME("Modulino Joystick"); PRINT_NAME("MCP23017 / PCF8574 (I/O Expander)"); }
  if (address == 0x23) PRINT_NAME("BH1750 (Light)");
  if (address == 0x24) PRINT_NAME("PN532 (NFC/RFID Reader)");
  if (address == 0x26) PRINT_NAME("STS40 (Temperature)");
  if (address == 0x27) PRINT_NAME("LCD I2C (PCF8574)");
  if (address == 0x28) PRINT_NAME("BNO055 (Smart IMU / Orientation)");
  if (address == 0x29) { PRINT_NAME("Modulino Distance"); PRINT_NAME("VL53L0X / VL53L1X (Distance)"); PRINT_NAME("TCS34725 (Color)"); }
  if (address == 0x2A) PRINT_NAME("NAU7802 (Qwiic Scale / Load Cell)");
  if (address == 0x2C) PRINT_NAME("CAP1188 (8-Ch Capacitive Touch)");
  if (address == 0x2D) PRINT_NAME("CAP1188 (Alt Address)");

  if (address == 0x33) PRINT_NAME("MLX90640 (IR Thermal Camera Array)");
  if (address == 0x34) PRINT_NAME("AXP192 / AXP202 (Power Management - M5Stack)");
  if (address == 0x36) { PRINT_NAME("Modulino Pixels"); PRINT_NAME("STEMMA Soil (Soil Moisture)"); }
  if (address == 0x38) { PRINT_NAME("AHT10 / AHT20 / AHT21 (Temp & Moisture)"); PRINT_NAME("VEML6070 (UV LSB)"); }
  if (address == 0x39) { PRINT_NAME("APDS9960 (Gesture/Color)"); PRINT_NAME("TSL2561 (Light)"); PRINT_NAME("VEML6070 (UV MSB)"); }
  if (address == 0x3A) PRINT_NAME("Modulino Knob");
  if (address == 0x3C) PRINT_NAME("OLED (SSD1306 / SH1106)");
  if (address == 0x3D) { PRINT_NAME("OLED (SSD1306 / SH1106)"); PRINT_NAME("Qwilino OLED"); }
  if (address == 0x3E) PRINT_NAME("Modulino Buttons");
  if (address == 0x3F) PRINT_NAME("LCD I2C (PCF8574A)");

  if (address == 0x40) { PRINT_NAME("HTU21D / Si7021 (Moisture)"); PRINT_NAME("PCA9685 (PWM)"); PRINT_NAME("INA219 (Current/Power)"); PRINT_NAME("HDC1080 (Temp & Moisture)"); }
  if (address == 0x41) PRINT_NAME("INA219 (Alternative Address)");
  if (address == 0x42) PRINT_NAME("U-blox GPS/GNSS (Qwiic)");
  if (address == 0x43) PRINT_NAME("SHTC3 (Temp & Moisture)");
  if (address == 0x44) { PRINT_NAME("Modulino Thermo"); PRINT_NAME("SHT3x / SHT4x"); PRINT_NAME("INA219 (Alternative)"); PRINT_NAME("ISL29125 (RGB)"); }
  if (address == 0x45) { PRINT_NAME("SHT3x / SHT4x (Alt Address)"); PRINT_NAME("INA219 (Alternative)"); }
  if (address == 0x47) PRINT_NAME("TMP117 (High-Precision Temp)");
  if (address == 0x48) { PRINT_NAME("ADS1115 / ADS1015 (ADC)"); PRINT_NAME("Qwilino Potentiometer"); }
  if (address == 0x49) { PRINT_NAME("ADS1115 / ADS1015 (ADC Alt)"); PRINT_NAME("Qwilino Temp"); }
  if (address == 0x4A) PRINT_NAME("MAX44009 (Light)");
  if (address == 0x4B) PRINT_NAME("SparkFun Qwiic Keypad");
  if (address == 0x4C) PRINT_NAME("EMC2101 (Fan Speed Controller / Temp)");
  if (address == 0x4D) PRINT_NAME("MAX17043 (LiPo Fuel Gauge)");

  if (address == 0x50) { PRINT_NAME("EEPROM (AT24C32 etc.)"); PRINT_NAME("Qwilino EEPROM"); }
  if (address == 0x51) { PRINT_NAME("PCF8563 RTC"); PRINT_NAME("Qwilino Clock"); }
  if (address == 0x52) PRINT_NAME("PAJ7620 (Gesture Sensor)");
  if (address == 0x53) { PRINT_NAME("Modulino Light (Light/Color)"); PRINT_NAME("ADXL345 (Accelerometer)"); }
  if (address == 0x55) PRINT_NAME("BQ27441 / BQ27xxx (LiPo Fuel Gauge)");
  if (address == 0x57) { PRINT_NAME("EEPROM (AT24C32 Alt)"); PRINT_NAME("MAX30105 (Pulse/Oximeter)"); }
  if (address == 0x58) PRINT_NAME("SGP30 (Air Quality / TVOC)");
  if (address == 0x59) PRINT_NAME("SGP40 (VOC / Air Quality)");
  if (address == 0x5A) { PRINT_NAME("MLX90614 (IR Temperature)"); PRINT_NAME("MPR121 (Capacitive Touch)"); PRINT_NAME("CCS811 (Air Quality)"); }
  if (address == 0x5B) PRINT_NAME("CCS811 (Alt Address)");
  if (address == 0x5C) { PRINT_NAME("BH1750 (Alt Address)"); PRINT_NAME("AM2320 (Temp & Moisture)"); }
  if (address == 0x5D) PRINT_NAME("VL6180X (ToF Range + Ambient Light)");
  if (address == 0x5F) PRINT_NAME("HTS221 (Humidity & Temp)");

  if (address == 0x60) { PRINT_NAME("MCP4725 (DAC)"); PRINT_NAME("TEA5767 (FM Radio)"); PRINT_NAME("Adafruit Motor Shield V2"); PRINT_NAME("ATECC608 (Crypto)"); PRINT_NAME("VEML6075 (UV)"); }
  if (address == 0x61) PRINT_NAME("SCD30 (CO2 / Humidity / Temp)");
  if (address == 0x62) PRINT_NAME("SCD40 / SCD41 (CO2 Sensor)");
  if (address == 0x63) PRINT_NAME("AS5600 (Magnetic Encoder)");
  if (address == 0x64) PRINT_NAME("SparkFun Qwiic Twist (RGB Encoder)");
  if (address == 0x68) { PRINT_NAME("MPU6050 / MPU9250 (IMU)"); PRINT_NAME("DS3231 / DS1307 RTC"); PRINT_NAME("AMG8833 (Thermal Camera)"); }
  if (address == 0x69) { PRINT_NAME("MPU6050 / MPU9250 (Alt Address)"); PRINT_NAME("AMG8833 (Thermal Camera Alt)"); }
  if (address == 0x6A) PRINT_NAME("Modulino Movement");
  if (address == 0x6B) { PRINT_NAME("Modulino Movement (Jumpered)"); PRINT_NAME("LSM6DS33 / L3GD20H (Pololu IMU)"); }
  if (address == 0x6C) PRINT_NAME("LPS22HB / LPS25HB (Barometric Pressure)");
  if (address == 0x6D) PRINT_NAME("LPS22HB (Alt Address)");
  if (address == 0x6F) PRINT_NAME("MCP7940N RTC");

  if (address == 0x70) { PRINT_NAME("TCA9548A (I2C Mux, Addr=0)"); PRINT_NAME("PCA9685 (Broadcast)"); PRINT_NAME("HT16K33 (LED Matrix)"); }
  if (address == 0x71) { PRINT_NAME("TCA9548A (I2C Mux, Addr=1)"); PRINT_NAME("HT16K33 (LED Matrix Alt)"); }
  if (address == 0x72) PRINT_NAME("TCA9548A (I2C Mux, Addr=2)");
  if (address == 0x73) PRINT_NAME("TCA9548A (I2C Mux, Addr=3)");
  if (address == 0x74) { PRINT_NAME("TCA9548A (I2C Mux, Addr=4)"); PRINT_NAME("IS31FL3731 (LED Driver)"); }
  if (address == 0x75) { PRINT_NAME("TCA9548A (I2C Mux, Addr=5)"); PRINT_NAME("ICM-20948 (9-Axis IMU)"); }
  if (address == 0x76) { PRINT_NAME("TCA9548A (I2C Mux, Addr=6)"); PRINT_NAME("BME280 / BMP280 / BME680"); PRINT_NAME("MS5611 / BMP388 (Barometer)"); }
  if (address == 0x77) { PRINT_NAME("TCA9548A (I2C Mux, Addr=7)"); PRINT_NAME("BMP180 / BME280 / BMP280 / BME680"); PRINT_NAME("MS5611 / BMP388 (Alt)"); }
  if (address == 0x7D) PRINT_NAME("SparkFun Qwiic RFID Reader");
  if (address == 0x7E) PRINT_NAME("Modulino Movement (Auxiliary)");

  if (isFirst) Serial.print(F("Unknown Device"));
  #undef PRINT_NAME
}

void printResults() {
  Serial.println(F("\n============  METE HOCA ADVANCED I2C SCANNER  ============"));

  if (foundCount == 0) {
    Serial.println(F("  No connected I2C devices found..."));
  } else {
    for (uint8_t i = 0; i < foundCount; i++) {
      const FoundDevice& device = foundDevices[i];

      Serial.print(F(" 0x"));
      if (device.address < 16) Serial.print(F("0"));
      Serial.print(device.address, HEX);

      Serial.print(F(" @ Wire"));
      if (device.portIdx > 0) Serial.print((int)device.portIdx);

      if (device.muxAddress != 0) {
        Serial.print(F(" [Mux:0x"));
        if (device.muxAddress < 16) Serial.print(F("0"));
        Serial.print(device.muxAddress, HEX);
        Serial.print(F(" Ch"));
        Serial.print((int)device.muxChannel);
        Serial.print(F("]"));
      }

      Serial.print(F("  =>  "));
      printDeviceNames(device.address);
      Serial.println();
    }
  }

  Serial.println(F("==========================================================\n"));
}

void setup() {
  while (!Serial && millis() < 3000);
  Serial.begin(115200);

#if (defined(WIRE_SDA_PIN) && defined(WIRE_SCL_PIN)) && \
    (defined(ARDUINO_ARCH_ESP32) || defined(ARDUINO_ARCH_RP2040))
  Wire.begin(WIRE_SDA_PIN, WIRE_SCL_PIN);
#else
  Wire.begin();
#endif
  Wire.setClock(100000UL);

#ifdef HAS_WIRE1
  #if (defined(WIRE1_SDA_PIN) && defined(WIRE1_SCL_PIN)) && \
    (defined(ARDUINO_ARCH_ESP32) || defined(ARDUINO_ARCH_RP2040))
    Wire1.begin(WIRE1_SDA_PIN, WIRE1_SCL_PIN);
  #else
  Wire1.begin();
#endif
  Wire1.setClock(100000UL);
#endif

#ifdef HAS_WIRE2
  Wire2.begin();
  Wire2.setClock(100000UL);
#endif

#ifdef HAS_WIRE3
  Wire3.begin();
  Wire3.setClock(100000UL);
#endif
}

void loop() {
  foundCount = 0;

  scanPort(Wire, 0);
#ifdef HAS_WIRE1
  scanPort(Wire1, 1);
#endif
#ifdef HAS_WIRE2
  scanPort(Wire2, 2);
#endif
#ifdef HAS_WIRE3
  scanPort(Wire3, 3);
#endif

  sortResults();
  printResults();
  delay(SCAN_INTERVAL_MS);
}

100

101

102

103

104

105

106

107

108

109

110

111

112

113

114

115

116

117

118

119

120

121

122

123

124

125

126

127

128

129

130

131

132

133

134

135

136

137

138

139

140

141

142

143

144

145

146

147

148

149

150

151

152

153

154

155

156

157

158

159

160

161

162

163

164

165

166

167

168

169

170

171

172

173

174

175

176

177

178

179

180

181

182

183

184

185

186

187

188

189

190

191

192

193

194

195

196

197

198

199

200

201

202

203

204

205

206

207

208

209

210

211

212

213

214

215

216

217

218

219

220

221

222

223

224

225

226

227

228

229

230

231

232

233

234

235

236

237

238

239

240

241

242

243

244

245

246

247

248

249

250

251

252

253

254

255

256

257

258

259

260

261

262

263

264

265

266

267

268

269

270

271

272

273

274

275

276

277

278

279

280

281

282

283

284

285

286

287

288

289

290

291

292

293

294

295

296

297

298

299

300

301

302

303

304

305

306

307

308

309

310

311

312

313

314

315

316

317

318

319

320

321

322

323

324

325

326

327

328

329

330

331

332

333

334

335

* ╔══════════════════════════════════════════════════════════════════╗

* ║ METE HOCA ADVANCED I2C SCANNER ║

* ╠══════════════════════════════════════════════════════════════════╣

* ║ OVERVIEW: ║

* ║ This advanced I2C scanner detects devices across multiple ║

* ║ hardware I2C buses (Wire, Wire1, Wire2, Wire3). It identifies ║

* ║ the connected modules and maps them to their common names. ║

* ║ ║

* ║ HOW TO USE: ║

* ║ Upload the code to your microcontroller, open the Serial Monitor ║

* ║ at 115200 baud, and observe the output. The scanner will refresh ║

* ║ automatically based on the SCAN_INTERVAL_MS definition. Custom ║

* ║ SDA/SCL pins can be defined manually for ESP32/RP2040 boards. ║

* ║ ║

* ║ SUBTLE POINTS & NUANCES: ║

* ║ • Mux Recursion: Automatically detects TCA9548A multiplexers ║

* ║ (0x70-0x77) and scans all 8 of their sub-channels individually.║

* ║ (If this causes conflicts, comment out ENABLE_MUX_SCAN). ║

* ║ • Strict Validation: endTransmission() must return exactly 0. ║

* ║ This filters out NACKs, timeouts, and buffer overruns. ║

* ║ • Arduino Uno R4 WiFi: Be aware that the physical Qwiic ║

* ║ connector on this board is tied to Wire1, not the default Wire.║

* ║ • Sorting Algorithm: Results are strictly sorted by Port -> ║

* ║ Mux Address -> Mux Channel -> Device Address for readability. ║

* ╚══════════════════════════════════════════════════════════════════╝

#include <Wire.h>

#define SCAN_INTERVAL_MS 3000

#define SCAN_DELAY_US 150

#define MAX_FOUND 32

#define ENABLE_MUX_SCAN

#if defined(WIRE_INTERFACES_COUNT)

#if WIRE_INTERFACES_COUNT >= 2

#define HAS_WIRE1

#endif

#if WIRE_INTERFACES_COUNT >= 3

#define HAS_WIRE2

#endif

#if WIRE_INTERFACES_COUNT >= 4

#define HAS_WIRE3

#endif

#else

#if defined(ARDUINO_UNOR4_WIFI) || defined(ARDUINO_NANO_R4) || \

defined(ARDUINO_ARCH_RP2040) || defined(ARDUINO_ARCH_STM32) || \

defined(CORE_TEENSY) || defined(ARDUINO_SAM_DUE) || \

defined(ARDUINO_ARCH_ESP32) || defined(ARDUINO_UNO_Q)

#define HAS_WIRE1

#endif

struct FoundDevice {

uint8_t address;

uint8_t portIdx;

uint8_t muxAddress;

uint8_t muxChannel;

};

FoundDevice foundDevices[MAX_FOUND];

uint8_t foundCount = 0;

bool probeAddress(TwoWire& wire, uint8_t address) {

wire.beginTransmission(address);

uint8_t error = wire.endTransmission();

delayMicroseconds(SCAN_DELAY_US);

return (error == 0);

}

bool isDevicePresent(const FoundDevice* deviceArray, uint8_t count,

uint8_t address, uint8_t portIdx,

uint8_t muxAddress, uint8_t muxChannel) {

for (uint8_t i = 0; i < count; i++) {

if (deviceArray[i].address == address &&

deviceArray[i].portIdx == portIdx &&

deviceArray[i].muxAddress == muxAddress &&

deviceArray[i].muxChannel == muxChannel) return true;

}

return false;

}

void addDevice(uint8_t address, uint8_t portIdx,

uint8_t muxAddress, uint8_t muxChannel) {

if (foundCount >= MAX_FOUND) return;

if (isDevicePresent(foundDevices, foundCount,

address, portIdx, muxAddress, muxChannel)) return;

foundDevices[foundCount++] = {address, portIdx, muxAddress, muxChannel};

}

#ifdef ENABLE_MUX_SCAN

void scanMux(TwoWire& wire, uint8_t portIdx, uint8_t muxAddress) {

for (uint8_t channel = 0; channel < 8; channel++) {

wire.beginTransmission(muxAddress);

wire.write(1 << channel);

if (wire.endTransmission() != 0) continue;

delayMicroseconds(200);

for (uint8_t address = 1; address < 127; address++) {

if (address >= 0x70 && address <= 0x77) continue;

if (probeAddress(wire, address)) {

addDevice(address, portIdx, muxAddress, channel);

}

wire.beginTransmission(muxAddress);

wire.write(0x00);

wire.endTransmission();

delayMicroseconds(100);

}

#endif

void scanPort(TwoWire& wire, uint8_t portIdx) {

for (uint8_t address = 1; address < 127; address++) {

if (probeAddress(wire, address)) {

addDevice(address, portIdx, 0, 0);

#ifdef ENABLE_MUX_SCAN

if (address >= 0x70 && address <= 0x77) {

scanMux(wire, portIdx, address);

}

#endif

}

void sortResults() {

if (foundCount < 2) return;

for (uint8_t i = 0; i < foundCount - 1; i++) {

for (uint8_t j = i + 1; j < foundCount; j++) {

bool swapNeeded = false;

const FoundDevice& a = foundDevices[i];

const FoundDevice& b = foundDevices[j];

if (a.portIdx > b.portIdx ) swapNeeded = true;

else if (a.portIdx == b.portIdx ) {

if (a.muxAddress > b.muxAddress) swapNeeded = true;

else if (a.muxAddress == b.muxAddress) {

if (a.muxChannel > b.muxChannel) swapNeeded = true;

else if (a.muxChannel == b.muxChannel && a.address > b.address) swapNeeded = true;

}

if (swapNeeded) {

FoundDevice temp = foundDevices[i];

foundDevices[i] = foundDevices[j];

foundDevices[j] = temp;

}

void printDeviceNames(uint8_t address) {

bool isFirst = true;

#define PRINT_NAME(s) do { if (!isFirst) Serial.print(F(", ")); \

Serial.print(F(s)); isFirst = false; } while(0)

if (address == 0x0D) PRINT_NAME("QMC5883L (Compass Clone)");

if (address == 0x0E) PRINT_NAME("Pololu Tic (Stepper Motor Driver)");

if (address == 0x10) PRINT_NAME("VEML7700 (Light)");

if (address == 0x14) PRINT_NAME("MAG3110 (Magnetometer)");

if (address == 0x15) PRINT_NAME("Modulino Latch Relay");

if (address == 0x18) { PRINT_NAME("MCP9808 (High-Precision Temp)"); PRINT_NAME("SparkFun Qwiic Relay"); }

if (address == 0x19) { PRINT_NAME("Modulino LED Matrix"); PRINT_NAME("LSM303 (Compass/Accel)"); }

if (address == 0x1A) PRINT_NAME("MAX9744 (Audio Amplifier)");

if (address == 0x1C) PRINT_NAME("MMA8452Q / FXOS8700 (Accelerometer)");

if (address == 0x1D) PRINT_NAME("Modulino Vibro");

if (address == 0x1E) { PRINT_NAME("Modulino Buzzer"); PRINT_NAME("HMC5883L / LIS3MDL (Compass)"); }

if (address == 0x20) { PRINT_NAME("Modulino Joystick"); PRINT_NAME("MCP23017 / PCF8574 (I/O Expander)"); }

if (address == 0x23) PRINT_NAME("BH1750 (Light)");

if (address == 0x24) PRINT_NAME("PN532 (NFC/RFID Reader)");

if (address == 0x26) PRINT_NAME("STS40 (Temperature)");

if (address == 0x27) PRINT_NAME("LCD I2C (PCF8574)");

if (address == 0x28) PRINT_NAME("BNO055 (Smart IMU / Orientation)");

if (address == 0x29) { PRINT_NAME("Modulino Distance"); PRINT_NAME("VL53L0X / VL53L1X (Distance)"); PRINT_NAME("TCS34725 (Color)"); }

if (address == 0x2A) PRINT_NAME("NAU7802 (Qwiic Scale / Load Cell)");

if (address == 0x2C) PRINT_NAME("CAP1188 (8-Ch Capacitive Touch)");

if (address == 0x2D) PRINT_NAME("CAP1188 (Alt Address)");

if (address == 0x33) PRINT_NAME("MLX90640 (IR Thermal Camera Array)");

if (address == 0x34) PRINT_NAME("AXP192 / AXP202 (Power Management - M5Stack)");

if (address == 0x36) { PRINT_NAME("Modulino Pixels"); PRINT_NAME("STEMMA Soil (Soil Moisture)"); }

if (address == 0x38) { PRINT_NAME("AHT10 / AHT20 / AHT21 (Temp & Moisture)"); PRINT_NAME("VEML6070 (UV LSB)"); }

if (address == 0x39) { PRINT_NAME("APDS9960 (Gesture/Color)"); PRINT_NAME("TSL2561 (Light)"); PRINT_NAME("VEML6070 (UV MSB)"); }

if (address == 0x3A) PRINT_NAME("Modulino Knob");

if (address == 0x3C) PRINT_NAME("OLED (SSD1306 / SH1106)");

if (address == 0x3D) { PRINT_NAME("OLED (SSD1306 / SH1106)"); PRINT_NAME("Qwilino OLED"); }

if (address == 0x3E) PRINT_NAME("Modulino Buttons");

if (address == 0x3F) PRINT_NAME("LCD I2C (PCF8574A)");

if (address == 0x40) { PRINT_NAME("HTU21D / Si7021 (Moisture)"); PRINT_NAME("PCA9685 (PWM)"); PRINT_NAME("INA219 (Current/Power)"); PRINT_NAME("HDC1080 (Temp & Moisture)"); }

if (address == 0x41) PRINT_NAME("INA219 (Alternative Address)");

if (address == 0x42) PRINT_NAME("U-blox GPS/GNSS (Qwiic)");

if (address == 0x43) PRINT_NAME("SHTC3 (Temp & Moisture)");

if (address == 0x44) { PRINT_NAME("Modulino Thermo"); PRINT_NAME("SHT3x / SHT4x"); PRINT_NAME("INA219 (Alternative)"); PRINT_NAME("ISL29125 (RGB)"); }

if (address == 0x45) { PRINT_NAME("SHT3x / SHT4x (Alt Address)"); PRINT_NAME("INA219 (Alternative)"); }

if (address == 0x47) PRINT_NAME("TMP117 (High-Precision Temp)");

if (address == 0x48) { PRINT_NAME("ADS1115 / ADS1015 (ADC)"); PRINT_NAME("Qwilino Potentiometer"); }

if (address == 0x49) { PRINT_NAME("ADS1115 / ADS1015 (ADC Alt)"); PRINT_NAME("Qwilino Temp"); }

if (address == 0x4A) PRINT_NAME("MAX44009 (Light)");

if (address == 0x4B) PRINT_NAME("SparkFun Qwiic Keypad");

if (address == 0x4C) PRINT_NAME("EMC2101 (Fan Speed Controller / Temp)");

if (address == 0x4D) PRINT_NAME("MAX17043 (LiPo Fuel Gauge)");

if (address == 0x50) { PRINT_NAME("EEPROM (AT24C32 etc.)"); PRINT_NAME("Qwilino EEPROM"); }

if (address == 0x51) { PRINT_NAME("PCF8563 RTC"); PRINT_NAME("Qwilino Clock"); }

if (address == 0x52) PRINT_NAME("PAJ7620 (Gesture Sensor)");

if (address == 0x53) { PRINT_NAME("Modulino Light (Light/Color)"); PRINT_NAME("ADXL345 (Accelerometer)"); }

if (address == 0x55) PRINT_NAME("BQ27441 / BQ27xxx (LiPo Fuel Gauge)");

if (address == 0x57) { PRINT_NAME("EEPROM (AT24C32 Alt)"); PRINT_NAME("MAX30105 (Pulse/Oximeter)"); }

if (address == 0x58) PRINT_NAME("SGP30 (Air Quality / TVOC)");

if (address == 0x59) PRINT_NAME("SGP40 (VOC / Air Quality)");

if (address == 0x5A) { PRINT_NAME("MLX90614 (IR Temperature)"); PRINT_NAME("MPR121 (Capacitive Touch)"); PRINT_NAME("CCS811 (Air Quality)"); }

if (address == 0x5B) PRINT_NAME("CCS811 (Alt Address)");

if (address == 0x5C) { PRINT_NAME("BH1750 (Alt Address)"); PRINT_NAME("AM2320 (Temp & Moisture)"); }

if (address == 0x5D) PRINT_NAME("VL6180X (ToF Range + Ambient Light)");

if (address == 0x5F) PRINT_NAME("HTS221 (Humidity & Temp)");

if (address == 0x60) { PRINT_NAME("MCP4725 (DAC)"); PRINT_NAME("TEA5767 (FM Radio)"); PRINT_NAME("Adafruit Motor Shield V2"); PRINT_NAME("ATECC608 (Crypto)"); PRINT_NAME("VEML6075 (UV)"); }

if (address == 0x61) PRINT_NAME("SCD30 (CO2 / Humidity / Temp)");

if (address == 0x62) PRINT_NAME("SCD40 / SCD41 (CO2 Sensor)");

if (address == 0x63) PRINT_NAME("AS5600 (Magnetic Encoder)");

if (address == 0x64) PRINT_NAME("SparkFun Qwiic Twist (RGB Encoder)");

if (address == 0x68) { PRINT_NAME("MPU6050 / MPU9250 (IMU)"); PRINT_NAME("DS3231 / DS1307 RTC"); PRINT_NAME("AMG8833 (Thermal Camera)"); }

if (address == 0x69) { PRINT_NAME("MPU6050 / MPU9250 (Alt Address)"); PRINT_NAME("AMG8833 (Thermal Camera Alt)"); }

if (address == 0x6A) PRINT_NAME("Modulino Movement");

if (address == 0x6B) { PRINT_NAME("Modulino Movement (Jumpered)"); PRINT_NAME("LSM6DS33 / L3GD20H (Pololu IMU)"); }

if (address == 0x6C) PRINT_NAME("LPS22HB / LPS25HB (Barometric Pressure)");

if (address == 0x6D) PRINT_NAME("LPS22HB (Alt Address)");

if (address == 0x6F) PRINT_NAME("MCP7940N RTC");

if (address == 0x70) { PRINT_NAME("TCA9548A (I2C Mux, Addr=0)"); PRINT_NAME("PCA9685 (Broadcast)"); PRINT_NAME("HT16K33 (LED Matrix)"); }

if (address == 0x71) { PRINT_NAME("TCA9548A (I2C Mux, Addr=1)"); PRINT_NAME("HT16K33 (LED Matrix Alt)"); }

if (address == 0x72) PRINT_NAME("TCA9548A (I2C Mux, Addr=2)");

if (address == 0x73) PRINT_NAME("TCA9548A (I2C Mux, Addr=3)");

if (address == 0x74) { PRINT_NAME("TCA9548A (I2C Mux, Addr=4)"); PRINT_NAME("IS31FL3731 (LED Driver)"); }

if (address == 0x75) { PRINT_NAME("TCA9548A (I2C Mux, Addr=5)"); PRINT_NAME("ICM-20948 (9-Axis IMU)"); }

if (address == 0x76) { PRINT_NAME("TCA9548A (I2C Mux, Addr=6)"); PRINT_NAME("BME280 / BMP280 / BME680"); PRINT_NAME("MS5611 / BMP388 (Barometer)"); }

if (address == 0x77) { PRINT_NAME("TCA9548A (I2C Mux, Addr=7)"); PRINT_NAME("BMP180 / BME280 / BMP280 / BME680"); PRINT_NAME("MS5611 / BMP388 (Alt)"); }

if (address == 0x7D) PRINT_NAME("SparkFun Qwiic RFID Reader");

if (address == 0x7E) PRINT_NAME("Modulino Movement (Auxiliary)");

if (isFirst) Serial.print(F("Unknown Device"));

#undef PRINT_NAME

}

void printResults() {

Serial.println(F("\n============ METE HOCA ADVANCED I2C SCANNER ============"));

if (foundCount == 0) {

Serial.println(F(" No connected I2C devices found..."));

} else {

for (uint8_t i = 0; i < foundCount; i++) {

const FoundDevice& device = foundDevices[i];

Serial.print(F(" 0x"));

if (device.address < 16) Serial.print(F("0"));

Serial.print(device.address, HEX);

Serial.print(F(" @ Wire"));

if (device.portIdx > 0) Serial.print((int)device.portIdx);

if (device.muxAddress != 0) {

Serial.print(F(" [Mux:0x"));

if (device.muxAddress < 16) Serial.print(F("0"));

Serial.print(device.muxAddress, HEX);

Serial.print(F(" Ch"));

Serial.print((int)device.muxChannel);

Serial.print(F("]"));

}

Serial.print(F(" => "));

printDeviceNames(device.address);

Serial.println();

}

Serial.println(F("==========================================================\n"));

}

void setup() {

while (!Serial && millis() < 3000);

Serial.begin(115200);

#if (defined(WIRE_SDA_PIN) && defined(WIRE_SCL_PIN)) && \

(defined(ARDUINO_ARCH_ESP32) || defined(ARDUINO_ARCH_RP2040))

Wire.begin(WIRE_SDA_PIN, WIRE_SCL_PIN);

#else

Wire.begin();

#endif

Wire.setClock(100000UL);

#ifdef HAS_WIRE1

#if (defined(WIRE1_SDA_PIN) && defined(WIRE1_SCL_PIN)) && \

(defined(ARDUINO_ARCH_ESP32) || defined(ARDUINO_ARCH_RP2040))

Wire1.begin(WIRE1_SDA_PIN, WIRE1_SCL_PIN);

#else

Wire1.begin();

#endif

Wire1.setClock(100000UL);

#endif

#ifdef HAS_WIRE2

Wire2.begin();

Wire2.setClock(100000UL);

#endif

#ifdef HAS_WIRE3

Wire3.begin();

Wire3.setClock(100000UL);

#endif

}

void loop() {

foundCount = 0;

scanPort(Wire, 0);

#ifdef HAS_WIRE1

scanPort(Wire1, 1);

#endif

#ifdef HAS_WIRE2

scanPort(Wire2, 2);

#endif

#ifdef HAS_WIRE3

scanPort(Wire3, 3);

#endif

sortResults();

printResults();

delay(SCAN_INTERVAL_MS);

}

I2C Arduino Modüllerinin Adres Numarası Nasıl Bulunur?

Güncel

BAŞKA BİR DÜNYA | UNI-T UT15C KALEM MULTİMETRE | DÜRÜST İNCELEME

ADC HESAPLARKEN 1023 MÜ? 1024 MÜ? | ARDUINO DERSLERİ

GÜZEL OYUNCAK | HYTAIS TS-U6 AKILLI MULTİMETRE | DÜRÜST İNCELEME

MULTİMETRE SATIN ALMA REHBERİ | ELEKTRONİK EĞİTİM | METE HOCA

HER EVE LAZIM! | UNI-T UT33A+ | DÜRÜST İNCELEME

MODULINO’LAR ARTIK ÖZGÜR! | QWILINO ARDUINO KÜTÜPHANESİ | METE HOCA

BEKLENENDEN İYİ | ZOYI ZT-DQ02 ESR METRE| DÜRÜST İNCELEME

MULTİMETRELERDE TOLERANS NEDİR? | ELEKTRONİK EĞİTİM | METE HOCA

BU KADAR İYİ OLAMAZ! | UNI-T UT89XE | DÜRÜST İNCELEME

AİLE GENİŞLİYOR | QWILINO XIAO ve CLOCK | METE HOCA
